Skyzone 04X PRO 5.8GHz 1920*1080 720P@100FPS FOV 52° OLED HD FPV Goggles

Skyzone 04X PRO 5.8GHz 1920*1080 720P@100FPS FOV 52° OLED HD FPV Goggles V3.3 Steadyview for FPV Drone RC Drone Pilots (Flagship Model)

Features

1. Upgraded OLED Display & Optics: Next-gen optics and OLED panel deliver 1920×1080 resolution, 100FPS frame rate, and 52° diagonal FOV -- offering a highly immersive FPV experience, especially when paired with digital VRX systems.

2. Enhanced Visual Performance: Supports 4:3/16:9 aspect ratios, with adjustable focus (-2~+6 diopters) and IPD (58-71mm) to fit diverse vision needs and face shapes.

3. Practical Matte Finish: New matte coating resists fingerprints and reduces glare for clearer viewing in various environments.

4. Reliable Reception & Recording: Equipped with a 5.8GHz 48CH V3.3 Steadyview Receiver and H.264 DVR (60fps) for stable signal capture and high-quality video recording.

5. Versatile Connectivity: Accepts 2~6S LiPo input and HDMI IN (720P 100FPS) for flexible setup with different FPV systems.

6. 3-Axis Head Tracking: Built-in 3-axis accelerometer and 3-axis gyroscope enable precise head movement control.

Important Note ：A cooling fan is installed in the right-side bay to regulate temperature for the high-performance OLED panel. As a result, the SKY04X PRO does not support diversity mode.

Specifications

Brand:

Skyzone

Model:

04X PRO

Screen Type

OLED

Resolution

1920×1080

Diagonal

FOV 52°

Aspect Ratio

4:3 / 16:9

Focus Adjustment

-2~+6 diopters (adjustable)

Interpupillary Distance

(IPD) 58-71mm

Receiver

5.8GHz 48CH V3.3 Steadyview Receiver

DVR

H.264, 60fps

Voltage Input

2~6S LiPo

HDMI IN

720P 100FPS

Head Tracker

3-axis Accelerometer, 3-axis Gyroscope

Color

Black/White/Red/Grey

Dimensions

(L×W×H) 185×75×67mm

Weight

267g

Comparison Dimension

SKY04O

(Basic Model)

SKY04O PRO

(Advanced Model)

SKY04X PRO (Flagship Model)

Screen

Performance

OLED,

1024×768 Resolution,

38° Diagonal FOV

OLED,

1280×720 Resolution,

42° Diagonal FOV

OLED,

1920×1080 Full HD,

52° Diagonal FOV (Best Immersion)

Reception

& Transmission

5.8GHz 48CH

Steadyview Receiver,

HDMI Input 60fps

5.8GHz 48CH

Steadyview Receiver,

HDMI Input 60fps,

Compatible with Walksnail Avatar

5.8GHz 48CH

V3.3 Steadyview Receiver

(Stronger Anti-Interference),

HDMI Input 720P 100fps

(Compatible with Digital System High Frame Rate Mode)

DVR

Recording

H.264 Encoding,

60fps,

Supports SD Card Expansion

MJPEG Encoding,

60fps, MOV Format (6Mbps),

Supports 128GB SD Card

H.264 Encoding,

60fps,

Clearer Recording Quality

Basic Adjustment

Functions

Adjustable Focus (-6~+2 Diopters),

IPD (58~71mm),

Supports 10 Languages

Same as SKY04O,

Consistent AdjustmentLogic

Same Series Adjustment Range,

New Matte Coating

(Fingerprint-Resistant & Anti-Glare)

Cooling & Special

Functions

No Independent Cooling,

Supports Diversity Mode

(Dual-Signal Fusion Anti-Tearing)

No Independent Cooling,

Supports Diversity Mode

Right-Side Independent Cooling Fan

(Adapts to HD OLED),

Does Not Support Diversity Mode

Power Supply

& Weight

2~6S LiPo Input,

Weight Not Disclosed

Dual Input (DC 6.5-25.2V/USB 5V),

Weight Not Disclosed,

Power Consumption 720mA@12V

2~6S LiPo Input,

267g,

185×75×67mm

Package Included:

1x SKY04X Pro Goggles

1x Steadyview V3.3 Receiver Module

2x Faceplate (wide and narrow)

1x Sponge

1x Zipper case

1x Power cable

1x Headtracker cable

2x 5.8GHz 2dB antennas

1x Video/Audio Cable

1xUSB-C Cable

1x SKY04x Pro User Manual
